FTIR and TGA can help identify and compare a defined rubber-track specimen, but they do not uniquely reconstruct its complete formulation. FTIR supports qualitative polymer identification from an infrared spectrum. TGA measures mass changes under stated thermal and atmospheric conditions, supporting broad compositional categories. Used together, these results can provide an analytical fingerprint—not proof that two tracks have identical recipes, mechanical properties or service life.

Before sending an unknown fragment to a laboratory, define its location, condition and comparator. Ask the laboratory to distinguish measured signals from chemical interpretations and to identify what remains unresolved.

Start with the fragment’s identity and location

An analytical result belongs to the specimen submitted. If nobody can establish where the fragment came from, the result cannot be confidently assigned to a particular track region or production item.

Document the track’s markings and the specimen’s position before sampling. Record whether the material represents a tread lug, another outer-rubber region or rubber adjacent to internal reinforcement. Include the approximate depth or layer where known, and distinguish an exposed surface from material taken beneath it.

Also record whether the specimen is unused, service-exposed, visibly contaminated or of unknown history. Do not assume that a surface fragment describes the original bulk compound. Equally, do not assume that a fragment from one location represents every rubber region in the track.

Where sampling would damage the track or consume material needed for another examination, obtain the owner’s authorization and agree on the sampling plan with the laboratory. This identification request is not a section-cutting or specimen-preparation procedure.

FTIR identifies polymer features, not the whole recipe

Fourier-transform infrared spectroscopy, or FTIR, produces a spectrum that the laboratory interprets against reference information. The useful question is whether the observed features support identification of a polymer or polymer family—not whether the spectrum reveals every ingredient and its exact quantity.

ISO’s public description of rubber identification methods covers raw rubber and vulcanized or unvulcanized mixes, including thermoplastic elastomers. It explicitly describes the methods as qualitative. Transmission and reflectance approaches are identified, so the examination route should remain visible in the report.

The ISO listing used for this review identifies ISO 4650:2012 as the previously published edition and a revision as under development. It does not establish a published ISO 4650:2026 edition. Ask the laboratory to state the exact edition or controlled method it actually uses rather than inserting an assumed current year.

For a useful FTIR record, request:

  • The specimen identifier and examined location

  • The examination approach and invoked method

  • The spectrum used for interpretation

  • The reference spectrum, library entry or authenticated comparator

  • The polymer assignment and the features supporting it

  • Any ambiguity, overlapping signals or constituents that cannot be resolved

A plausible spectral match is an interpretation of the tested material. It is not a verified ingredient list.

TGA measures fractions before assigning chemicals

Thermogravimetric analysis, or TGA, records changes in specimen mass under defined conditions. ASTM E1131-25 describes a general technique for determining highly volatile matter, medium volatile matter, combustible material and ash content. Its scope includes inert and reactive gas environments, and it allows an agreed analysis basis suited to the material.

Those categories are not automatically individual chemical ingredients. A reported mass-loss interval may contain contributions from more than one constituent. Residue is a measured quantity; identifying what produced that residue is a separate interpretation.

ASTM E1131 also states that analytical parameters can be changed to suit a particular analysis, provided the changes are reported. Consequently, two fraction summaries should not be compared without knowing the conditions and allocation rules behind them.

Ask the laboratory to retain:

  • The mass-versus-temperature or mass-versus-time record used

  • The thermal programme and atmospheric conditions

  • The boundaries used to assign reported fractions

  • Any changes from the invoked method

  • The basis for attributing a fraction to a chemical category

  • Fractions or constituents that remain unresolved

These are recommended procurement-review inputs, not a claim that the public standard mandates this exact report layout.

Keep the claim at the level of the signal

Use the following claim ladder when reviewing the combined results. It separates what was measured from what was inferred.

Evidence available Supported conclusion Conclusion that still needs separate evidence
FTIR spectrum with documented reference comparison Qualitative polymer identification or a stated tentative assignment for the specimen Exact blend proportions or a complete formulation
TGA curve with stated conditions and fraction boundaries Measured mass-loss and residue categories under that analysis basis Unique identification of every ingredient contributing to each fraction
Matched FTIR and TGA examinations of an unknown and a known comparator Similarities and differences within the sensitivity and scope of those examinations Identical recipes or identical manufacturing histories
Specimen-to-part and batch records The analytical result is traceable to the identified sampled item Uniformity throughout every region or unit in the lot
Analytical fingerprint alone Bounded chemical evidence Mechanical equivalence, complete cure, fitment or expected track life

A laboratory can report that two specimens have similar spectra and broad fraction results while still leaving blend proportions, minor additives or particular chemical assignments unresolved. Preserve those limits.

If the purpose is purchase acceptance, locate the controlled acceptance criterion separately. “Same as the reference” is too broad unless the comparison defines the reference, methods, features being evaluated and decision authority.

Give the laboratory a bounded identification request

Prepare one request that contains the following:

  1. Identity: Track markings, part reference, specimen identifier and any available batch relationship.

  2. Location: A photograph or location map showing the sampled region, layer and depth where known.

  3. Exposure: Known service, storage or contamination history, with unknowns explicitly recorded.

  4. Question: The polymer identity or broad compositional difference you need resolved.

  5. Comparator: An authenticated reference specimen, its identity and why it is relevant. If none exists, state that.

  6. Methods: The proposed FTIR and TGA methods and actual editions or laboratory procedure revisions.

  7. Interpretation basis: Reference spectra, mass-loss conditions, fraction-allocation rules and the requested uncertainty statement.

  8. Unresolved constituents: What cannot be identified or allocated, and what further analytical question the laboratory recommends.

  9. Sampling authority: Who authorized destructive or consumptive sampling and any limits on specimen use.

For example, “identify the polymer family and compare the broad mass-loss profile with this authenticated reference” is a narrower, answerable request than “prove this track uses the same compound.” The latter asks for equivalence beyond what these signals alone establish.

When discussing a quoted KTSU rubber track, use the candidate part identity, specimen location and analytical question to request whatever relevant documentation is available. The public rubber-track collection identifies the product family; it does not establish that KTSU performs FTIR or TGA testing.

The request is complete when the laboratory can identify exactly what material it will examine, what comparison it will make and where its interpretation must stop. The resulting report should preserve unresolved constituents rather than turn an analytical fingerprint into a reconstructed recipe or whole-track equivalence claim.
